|Usage:||hydrualic small home lift elevator wheelchair lift for apartments||Drive Type:||Hydraulic|
|Elevator Type:||Passenger Elevators||Material:||Aluminum Alloy|
|installation:||on the ground||Table Size:||1430mm(L) * 900mm(W)|
|Control:||Calling box and remote controller||Lift Drive:||Hydraulic cylinder|
|Lift Mechanism:||Lift Chain||OEM:||Available|
|Loading capacity:||250kgs||Lifting \/travel height:||4000mm|
patient lifting hoists,
disability lifting equipment
250kgs 4M Wheelchair Lift Elevator Disable Wheelchair Lift Platform for Home Use:
The wheelchair lift elevator is a device to transport wheelchair or motorized scooter and individual from one floor to another. It allows user to move freely within a multi-floored building. It is widely used for home, indoor and outdoor of public building.
Customized product can be done as your request, please tell us load weight, lift height, and platform size, our engineer will design a suitable lift for you soon.
|Max. Platform Height||4000mm|
|Platform size||1450mm(L)* 9000mm(W)|
|Min Platform height||70mm|
|In and out||180°in and out|
|Material||Stainless steel or aluminum alloy with Powder coating|
|Convenient operation design:|
|Control Mode||Inching Switch|
|Drive Control||Self-resetting system|
|Calling device||Calling box (Located at ground and upstairs), remote controller (optional)|
|Column switch||Two column switches, one is on the ground floor, one on the first floor|
|Working temperature||From -10°~60°C|
|Overload||Protection over current relay|
|Automatic ramp||75°ramp Range|
|Working Condition||Both indoors and outdoors|
|Installation||Non-pit installation, directly fixed to concrete floor|
|Safety Interlock:||Lock the platform when it is out of control|
|Emergency Stop||The lift can be stopped immediately in case of any emergency|
|Emergency Lowering||The platform can be lowered by manual down button in case of power failure|
|Safety Sensor||The lift will be stopped immediately if the safety edge meets obstacles when going down.|
|Auto-flap ramp||Turn up to max 75°and prevent the wheelchair outside|
Pictures of lift chair for disabled:
Load capacity : 250kgs
Max. Platform Height: 4M
Platform size: 1450mm(L)* 900mm(W)
We can according to your request for your custom.
Product part of the show:
The customers visiting:
1) We can design the wheelchair lift elevator as per your requirement.
2) The most suitable wheelchair lift elevator will be recommended to you once we get your requirement.
3) Shipment can be arranged from our port to your destination port.
4) Operation video can be sent to you if needed.
5) User-friendly English manual for machine installation using and maintenance.
6) 2 year warranty for whole machine without man-made faults.
7) We will send you parts for free if there are any non-human factors faults during warranty time.
8) Supply 24-hours technical assistance by email, telephone or other communication online.
9) We could reply you in 2 hours after received your any questions even on weekend and holiday.
Engineers are available to your country if necessary.
Delivery Time: 10 - 25 days
Payments: T/T and L/C, other kinds, pls contact with us
MOQ: 1 set
Trade term: FOB/CIF to your nearest seaport
Application field: Construction, shipyard, industrial, airport, municipal garden or others
