500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE

500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE
500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE 500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE 500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE 500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE 500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE

Duży Obraz :  500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE

Szczegóły Produktu:
Place of Origin: China
Nazwa handlowa: SDLIFT Or OEM
Orzecznictwo: CE TUV SGS
Model Number: SJG0.5-10
Zapłata:
Minimum Order Quantity: 1 UNIT
Cena: USD5980- USD9900 / UNIT
Packaging Details: Iron case or plywood case package
Delivery Time: 5-20 work days
Supply Ability: 3600units per year

500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE

Opis
Application: Warehouse Cargo Scissor Lift Power Supply: 220V/240V/380V/415V (as request)
Safe Device: Explosion-Proof Lock Valve Lift System: Hydraulic System
Color: red, grey, yellow, blue, or as your optional Load Capacity: 1 ton - 30 ton
Lift height: 1m - 12m Material: high strength Manganese Steel
Platform size: 2.3m x 1.55m
High Light:

material handling lifts

,

hydraulic lift platform

500kgs 10M Hydraulic Cargo Lift Vertical Material Scissor Lift Platform with CE:



Product's description:



- The hydraulic scissor lift can be used to lift cargo with different levels, suitable for cargo moving between stairs, from basement to first floor, or to second floor.
- Operation is easy. There are 2 sets control system installed on the stationary scissor lift, 1 control box below, and 1 hand controller on safety guard rail that can be operated on work platform.



Configuration:



1) Platform Material: rectangular tube + checkered anti-slip plate
2) Support scissors:  high strength Manganese Steel.
3) Hydraulic system: 380V/4.0Kw or 220v or as your request
4) Piston Rod:  hard chromium plating surface.



Safety:


1) Explosion-proof lock valve to avoid a sudden drop if emergency occurs

2) The safety guard rails to guarantee safety of the car above platform

3) The limit switch system helps the car parking lift hydraulic scissor car lift to stop at accurate position

4) Electricity leakage protection device is equipped on, all electric components are CE certified.

5) All the double scissor car lifts are passed 1.2 times loading test before leaving factory.



The models we supplied for clients:





MODEL LOAD CAPACITY PLATFORM SIZE LIFT HEIGHT PIT DEPTH POWER
SJG2.5-3 2.5T 5.2m x 2.6m 3m 750mm 220V, 240V, 380V or 400V
SJG2-6.5 2T 5.2m x 2.8m 6.5m 750mm 220V, 240V, 380V or 400V
SJG2.5-3.5 2.5T 5.2m x 2.6m 3.5m 800mm 220V, 240V, 380V or 400V
SJG2.5-5 2.5T 5.6m x 3m 5m 750mm 220V, 240V, 380V or 400V
SJG3-2.5 3T 5m x 2.3m 2.5m 750mm 220V, 240V, 380V or 400V
SJG3-3 3T 5.2m x 2.6m 3m 800mm 220V, 240V, 380V or 400V
SJG3-3.5 3T 5.6m x 2.7m 3.5m 800mm 220V, 240V, 380V or 400V
SJG5-10 5T 4.5m x 2.5m 10m 1150mm 220V, 240V, 380V or 400V
SJG8-2.5 8T 6.5m x 4.5m 2.5m 850mm 220V, 240V, 380V or 400V
SJG12-3 12T 5.5m x 2.8m 3m 950mm 220V, 240V, 380V or 400V
SJG15-4.5 15T 8m x 2.2m 4.5m 1050mm 220V, 240V, 380V or 400V
SJG20-5 20T 6m x 3m 5m 950mm 220V, 240V, 380V or 400V
The Hydraulic Cargo Scissor Lift​ can be customized as your detailed size.



Our services:

1) We can design the electric scaffolding as per your requirement.
2) The most suitable electric scaffolding will be recommended to you once we get your requirement.
3) Shipment can be arranged from our port to your destination port.
4) Operation video can be sent to you if needed.
5) User-friendly English manual for machine installation using and maintenance.
6) 2 years warranty for whole machine without man-made faults
7) We will send you parts for free if there are any non-human factors faults during warranty time.
8) Supply 24-hours technical assistance by email, telephone or other communication online.
9)We could reply you in 2 hours after received your any questions even on weekend and holiday. Engineers are available to your country if necessary.

Mian Parameters:



500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE 0500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE 1



Detailed Images:

500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE 2

500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE 3500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE 4





500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE 5



​The products showing:


500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE 6500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE 7

500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE 8500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE 9
500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE 10



500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE 11



500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE 12



The Certificates:



500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE 13



Contact Us: If you intrested, contact us freely.



500kgs 10M Hydraulic Heavy Duty Scissor Lift Vertical Material Scissor Lift Platform With CE 14
